| Nama Wahi | R196U2-L01 |
| Waitohu | Innolux |
| Rahi | 19.6 |
| Taupānga | MD |
| Whakatau | 1600×1200 |
| Te tito | LCM |
| Tirohanga | 600 |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | CMO |
| panel model | R196U2-L01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 19.6 inch |
| resolution | 1600(RGB)×1200 , UXGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 398.4×298.8 mm |
| outline | 427×322.4×38.3 mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| brightness | 600 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 25/25 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 16 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8-bit), 40 pins |
| input voltage | 12.0V (Typ.) |
| rohs: | |
| application | MD |
| LQ201U1LW18 | SHARP | 20.1 | 1600×1200 |
| NL160120AC27-37 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| R190EFE-L61 | Innolux | 19.0 | 1280×1024 |
| R196U2-L01 | Innolux | 19.6 | 1600×1200 |
| R208RFE-L05 | Innolux | 20.8 | 2048×1536 |
| R300M1-L01 | Innolux | 30.0 | 4096×2560 |
| R300SFE-L02 | Innolux | 30.0 | 3280×2048 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
