Innolux N154I6-L03 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com

N154I6-L03


Waitohu
Innolux
Rahi
15.4
Taupānga
NBPC
Whakatau
1280×800
Te tito
LCM
Tirohanga
200
CR
500:1
Nga Tae
262K
Whakamuri
WLED
Atanga
LVDS
In Stock
17994
Whakatakotoranga

Nama Wahi N154I6-L03
WaitohuInnolux
Rahi15.4
TaupāngaNBPC
Whakatau1280×800
Te titoLCM
Tirohanga200
CR500:1
Nga Tae262K
WhakamuriWLED
AtangaLVDS
panel brandCMO
panel modelN154I6-L03
panel type a-Si TFT-LCD , LCM
panel size15.4 inch
resolution1280(RGB)×800 , WXGA
display modeTN, Normally White, Transmissive
active area331.2×207 mm
outline344×222×6.2 mm
shape styleWedge (PCBA Bent, Depth ≥5.2mm)
surfaceGlare (Haze 0%), Hard coating (3H)
brightness200 cd/m² (Typ.)
contrast ratio500:1 (Typ.)
display colors262K (6-bit)
response time3/5 (Typ.)(Tr/Td)
viewing angle45/45/20/45 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type8S6PWLEDEmbedded (LED Driver)
signal interfaceLVDS (1 ch, 6-bit), 30 pins
input voltage3.3V (Typ.)
applicationNBPC
