| Nama Wahi | MT236FHM-N10 |
| Waitohu | BOE |
| Rahi | 23.6 |
| Taupānga | Desktop Monitor Gami |
| Whakatau | 1920×1080 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | BOE |
| model name | MT236FHM-N10 |
| screen size | 23.6 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1920(RGB)×1080 (FHD) 93PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 521.28 × 293.22 (H×V) |
| outline(mm) | 544.18 × 320.5 × 13.1 (H×V×D) |
| bezel area(mm) | 525.22 × 297.22 (H×V) |
| treatment | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 300 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
| response | 1.5/3.5 (Typ.)(Tr/Td) ms |
| good view at | - |
| work mode | TN, Normally White, Transmissive |
| color depth | 16.7M 76% NTSC |
| backlight | WLED , 30K hours , No Driver |
| mass | 2.06Kgs (Typ.) |
| used for | Desktop Monitor Gaming |
| refresh rate | 144Hz |
| touchscreen | Without |
| signal type | LVDS (4 ch, 8-bit) , 92 pins Connector |
| voltage supply | 5.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| HM236WU3-100 | BOE | 23.6 | 1920×1080 |
| HT236F01-100 | BOE | 23.6 | 1920×1080 |
| HV236WHB-N00 | BOE | 23.6 | 1366×768 |
| LK235D3HA0S | SHARP | 23.6 | 1920×1080 |
| M236H1-L01 | Innolux | 23.6 | 1920×1080 |
| M236HGE-L20 | Innolux | 23.6 | 1920×1080 |
| M236HGK-L30 | Innolux | 23.6 | 1920×1080 |
| M236MWF1 R0 | IVO | 23.6 | 1920×1080 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P03 | Innolux | 23.6 | 1366×768 |
