M236HGK-L30

M236HGK-L30
M236HGK-L30
M236HGK-L30
M236HGK-L30 thumb M236HGK-L30 thumb M236HGK-L30 thumb
Waitohu
Innolux
Rahi
23.6
Taupānga
DMPC
Whakatau
1920×1080
Te tito
LCM
Tirohanga
250
CR
1000:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
LVDS
In Stock
135
Whakatakotoranga

Nama Wahi M236HGK-L30
WaitohuInnolux
Rahi23.6
TaupāngaDMPC
Whakatau1920×1080
Te titoLCM
Tirohanga250
CR1000:1
Nga Tae16.7M
WhakamuriWLED
AtangaLVDS
panel brandINNOLUX
panel modelM236HGK-L30
panel type a-Si TFT-LCD , LCM
panel size23.6 inch
resolution1920(RGB)×1080 , FHD
display modeTN, Normally White, Transmissive
active area521.28×293.22 mm
outline550×325×16.13 mm
surfaceHard coating (6H)
brightness250 cd/m² (Typ.)
contrast ratio1000:1 (Typ.)
display colors16.7M (8-bit), CIE193172%
response time5 (Typ.)(Tr+Td)
viewing angle85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type4 stringsWLEDWithout Driver
signal interfaceLVDS (2 ch, 8-bit), 30 pins
input voltage5.0V (Typ.)
applicationDMPC
