| Nama Wahi | M236HJK-L5B |
| Waitohu | Innolux |
| Rahi | 23.6 |
| Taupānga | DMPC |
| Whakatau | 1920×1080 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 3000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | INNOLUX |
| panel model | M236HJK-L5B |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 23.6 inch |
| resolution | 1920(RGB)×1080 , FHD |
| display mode | Super MVA, Normally Black, Transmissive |
| active area | 521.28×293.22 mm |
| outline | 544.68×318.9×16.91 mm |
| surface | Hard coating (6H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 3000:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 20/5 (Typ.)(Tr/Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
