M240HW02 V1

M240HW02 V1
M240HW02 V1
M240HW02 V1
M240HW02 V1 thumb M240HW02 V1 thumb M240HW02 V1 thumb
Waitohu
AUO
Rahi
24.0
Taupānga
DMPC
Whakatau
1920×1080
Te tito
LCM
Tirohanga
250
CR
3000:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
LVDS
In Stock
131
Whakatakotoranga

Nama Wahi M240HW02 V1
WaitohuAUO
Rahi24.0
TaupāngaDMPC
Whakatau1920×1080
Te titoLCM
Tirohanga250
CR3000:1
Nga Tae16.7M
WhakamuriWLED
AtangaLVDS
panel brandAUO
panel modelM240HW02 V1
panel type a-Si TFT-LCD , LCM
panel size24.0 inch
resolution1920(RGB)×1080 , FHD
display modeMVA, Normally Black, Transmissive
active area531.36×298.89 mm
outline556×323.2×11.5 mm
surfaceAntiglare, Hard coating (3H)
brightness250 cd/m² (Typ.)
contrast ratio3000:1 (Typ.)
display colors16.7M (8-bit), CIE193173%
response time16/9 (Typ.)(Tr/Td)
viewing angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type15S4PWLEDWithout Driver
signal interfaceLVDS (2 ch, 8-bit), 30 pins
input voltage5.0V (Typ.)
applicationDMPC
