AUO M240HTN01.1 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


M240HTN01.1

M240HTN01.1
M240HTN01.1
M240HTN01.1
M240HTN01.1 thumb M240HTN01.1 thumb M240HTN01.1 thumb
Waitohu
AUO
Rahi
24.0
Taupānga
DMPC
Whakatau
1920×1080
Te tito
LCM
Tirohanga
200
CR
600:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
LVDS
In Stock
24
Whakatakotoranga

Nama Wahi M240HTN01.1
WaitohuAUO
Rahi24.0
TaupāngaDMPC
Whakatau1920×1080
Te titoLCM
Tirohanga200
CR600:1
Nga Tae16.7M
WhakamuriWLED
AtangaLVDS
panel brandAUO
panel modelM240HTN01.1
panel type a-Si TFT-LCD , LCM
panel size24.0 inch
resolution1920(RGB)×1080 , FHD
display modeTN, Normally White, Transmissive
active area531.36×298.89 mm
outline556×323.2×12 mm
surfaceAntiglare, Hard coating (3H)
brightness200 cd/m² (Typ.)
contrast ratio600:1 (Typ.)
display colors16.7M (6-bit + Hi-FRC)
response time3.5/1.5 (Typ.)(Tr/Td)
viewing angle45/45/20/45 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type8S4PWLEDWithout Driver
signal interfaceLVDS (2 ch, 8-bit), 30 pins
input voltage5.0V (Typ.)
applicationDMPC
