| Nama Wahi | HV236WHB-N00 |
| Waitohu | BOE |
| Rahi | 23.6 |
| Taupānga | DMPC |
| Whakatau | 1366×768 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | No B/L |
| Atanga | LVDS |
| panel brand | BOE |
| panel model | HV236WHB-N00 |
| panel type | a-Si TFT-LCD , CELL |
| panel size | 23.6 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | ADS, Normally Black, Transmissive |
| active area | 521.471×293.148 mm |
| outline | 535.47×306.404 mm |
| surface | Antiglare (Haze 1%), Hard coating (3H) |
| glass depth | 0.50+0.50 mm |
| transmissivity | 5.8% (Typ.)(with Polarizer) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC) |
| response time | 14 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 12.0V (Typ.) |
| application | DMPC |
