| Nama Wahi | M230HCJ-L3N Rev.C1 |
| Waitohu | Innolux |
| Rahi | 23.0 |
| Taupānga | Desktop Monitor |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 4 |
| Atanga | LVDS |
| panel brand | Innolux |
| panel model | M230HCJ-L3N Rev.C1 |
| panel size | 23.0" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1920(RGB)×1080, FHD, 95PPI |
| pixel format | RGB Vertical Stripe |
| display area | 509.184(W)×286.416(H) mm |
| bezel opening | 512.38(W)×289.62(H) mm |
| outline size | 522.38(W)×305.62(H) mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| display mode | AAS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 8/7 (Typ.)(Tr/Td) |
| display colors | 16.7M 72% NTSC |
| lamp type | 4 strings WLED , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 1.96/2.06/2.23Kgs (Min./Typ./Max.) |
| application | Desktop Monitor |
| signal interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| input voltage | 5.0V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
