| Nama Wahi | M090AWP4 R1 |
| Waitohu | IVO |
| Rahi | 9.0 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 800×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 700:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | Parallel |
| manufacturer | IVO |
| screen size | 9.0 inch |
| pixel number | 800(RGB)×480 (WVGA) 104PPI |
| active area(mm) | 198 × 112.08 (H×V) |
| bezel area(mm) | 200.2 × 114.28 (H×V) |
| luminance | 750 cd/m² (Typ.) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10) |
| good view at | 6 o'clock |
| color depth | 262K 70% NTSC |
| mass | - |
| refresh rate | 60Hz |
| signal type | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| max. ratings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| model name | M090AWP4 R1 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| treatment | Antiglare, Hard coating (3H) |
| contrast ratio | 700 : 1 (Typ.) (TM) |
| response | 12 (Typ.)(Tr+Td) ms |
| work mode | TN, Normally White, Transmissive |
| backlight | WLED , No Driver |
| used for | Outdoor High Brightness Automotive Display |
| touchscreen | Without |
