| Nama Wahi | LTP280QV-E01 |
| Waitohu | Samsung |
| Rahi | 2.8 |
| Taupānga | MPH |
| Whakatau | 240×320 |
| Te tito | LCM |
| Tirohanga | 110 |
| CR | 150:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SAMSUNG |
| panel model | LTP280QV-E01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 2.8 inch |
| resolution | 240(RGB)×320 , QVGA |
| display mode | TN, Normally White, Transflective |
| active area | 43.2×57.6 mm |
| outline | 52.9×71.7×4.75 mm |
| surface | Hard coating (3H) |
| brightness | 110 cd/m² (Typ.) |
| contrast ratio | 150:1 (Typ.)(Transmissive)6:1 (Typ.)(Reflective) |
| display colors | 262K (6-bit), CIE193130% |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 50/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 61 pins |
| input voltage | 3.3/5.0/15/-10V (Typ.)(DVDD/AVDD/VON/VOFF) |
| application | MPH |
| 28QVF1H | SII | 2.8 | 240×320 |
| 28QVF1J | SII | 2.8 | 240×320 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| LS028B7UX01 | SHARP | 2.8 | 240×400 |
| LTP280QV-E01 | Samsung | 2.8 | 240×320 |
| PJ028MA-01A | Innolux | 2.8 | 240×320 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TFT240320-237-E | Other | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| H466TAN01.1 | AUO | 4.7 | 720×1280 |
| H497TLB01 | AUO | 5.0 | 720×1280 |
| LH400WV3-SD05 | LG Display | 4.0 | 480×800 |
| LM18WGSBZ05 | SHARP | 1.8 | 120×160 |
| LQ047K3SX06 | SHARP | 4.7 | 720×1280 |
| LS023B3UY01 | SHARP | 2.3 | 360×400 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| PJ045IC-01F | Innolux | 4.5 | 720×1280 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
| TX08D13VM0AAA | KOE | 3.0 | 240×400 |
