| Nama Wahi | LTM270TT01 |
| Waitohu | Samsung |
| Rahi | 27.0 |
| Taupānga | DMPC |
| Whakatau | 2048×1152 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTM270TT01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 27.0 inch |
| resolution | 2048(RGB)×1152 , WDXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 597.5×336.1 mm |
| outline | 631.4×370 mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193192% |
| response time | 5 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | CCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
| LM270WF4-TLA1 | LG Display | 27.0 | 1920×1080 |
| LTM270DL02 | Samsung | 27.0 | 2560×1440 |
| LTM270DL04 | Samsung | 27.0 | 2560×1440 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| LTM270HL02 | Samsung | 27.0 | 1920×1080 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| LTM270TT01 | Samsung | 27.0 | 2048×1152 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| LM190E08-TLL3 | LG Display | 19.0 | 1280×1024 |
| LM201U05-SLA3 | LG Display | 20.1 | 1600×1200 |
| LM215WF4-TRA1 | LG Display | 21.5 | 1920×1080 |
| LQ150X1DG11 | SHARP | 15.0 | 1024×768 |
| LTM15C423S | TOSHIBA | 15.0 | 1024×768 |
| M200HJJ-L20 | Innolux | 19.5 | 1920×1080 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L03 | Innolux | 22.0 | 1680×1050 |
| M240HTN01.1 | AUO | 24.0 | 1920×1080 |
| M240HW01 VB | AUO | 24.0 | 1920×1080 |
