| Nama Wahi | LTI460AA01-001 |
| Waitohu | Samsung |
| Rahi | 46 |
| Taupānga | PID |
| Whakatau | 1366×768 |
| Te tito | LCM |
| Tirohanga | 700 |
| CR | 2000:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTI460AA01-001 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 46 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | S-PVA, Normally Black, Transmissive |
| active area | 1018.35×572.544 mm |
| outline | 1047.4×600.6×59.3 mm, Videowall Seam 29.0 mm |
| surface | Glare (Haze 0%), Hard coating (3H) |
| brightness | 700 cd/m² (Typ.) |
| contrast ratio | 2000:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 24 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 12.0V (Typ.) |
| application | PID |
