| Nama Wahi | ND168TXP01 |
| Waitohu | |
| Rahi | 16.8 |
| Taupānga | PID |
| Whakatau | 1366×378 |
| Te tito | LCM |
| Tirohanga | 800 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | |
| panel model | ND168TXP01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 16.8 inch(1/2 cut of 18.5") |
| resolution | 1366(RGB)×378 |
| display mode | TN, Normally White, Transmissive |
| active area | 409.8×113.4 mm |
| outline | 430.37×137.3×11.5 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 800 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193171% |
| response time | 5 (Typ.)(Tr+Td) |
| viewing angle | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | PID |
