| Nama Wahi | LTI820HA01 |
| Waitohu | Samsung |
| Rahi | 82 |
| Taupānga | PID |
| Whakatau | 1920×1080 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 5000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTI820HA01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 82 inch |
| resolution | 1920(RGB)×1080 , FHD |
| display mode | S-PVA, Normally Black, Transmissive |
| active area | 1805.76×1015.74 mm |
| outline | 1856×1082×44.8 mm |
| surface | Antiglare (Haze 2.3%), Hard coating (2H) |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 5000:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193170% |
| response time | 8 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| input voltage | 12.0V (Typ.) |
| application | PID |
