| Nama Wahi | LMS501KF03 |
| Waitohu | Samsung |
| Rahi | 5.0 |
| Taupānga | MPH |
| Whakatau | 480×800 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SAMSUNG SMD |
| panel model | LMS501KF03 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 5.0 inch |
| resolution | 480(RGB)×800 , WVGA |
| display mode | mPVA, Normally Black, TMR |
| active area | 65.52×109.2 mm |
| outline | 71.4×120.4×2.7 mm |
| surface | Hard coating (3H) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193150% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 6S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 51 pins |
| input voltage | 1.8/3.0V (Typ.)(VDD1/VDD3) |
| application | MPH |
