LG Display LM185WH2-TLD1 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


LM185WH2-TLD1

LM185WH2-TLD1
LM185WH2-TLD1
LM185WH2-TLD1
LM185WH2-TLD1 thumb LM185WH2-TLD1 thumb LM185WH2-TLD1 thumb
Waitohu
LG Display
Rahi
18.5
Taupānga
DMPC
Whakatau
1366×768
Te tito
LCM
Tirohanga
200
CR
600:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
LVDS
In Stock
5564
Whakatakotoranga

Nama Wahi LM185WH2-TLD1
WaitohuLG Display
Rahi18.5
TaupāngaDMPC
Whakatau1366×768
Te titoLCM
Tirohanga200
CR600:1
Nga Tae16.7M
WhakamuriWLED
AtangaLVDS
panel brandLG Display
panel modelLM185WH2-TLD1
panel type a-Si TFT-LCD , LCM
panel size18.5 inch
resolution1366(RGB)×768 , WXGA
display modeTN, Normally White, Transmissive
active area409.8×230.4 mm
outline430.4×254.6×10.7 mm
surfaceAntiglare, Hard coating (3H)
brightness200 cd/m² (Typ.)
contrast ratio600:1 (Typ.)
display colors16.7M (6-bit + Hi-FRC)
response time1.1/3.9 (Typ.)(Tr/Td)
viewing angle45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type11S2PWLEDWithout Driver
signal interfaceLVDS (1 ch, 8-bit), 30 pins
input voltage5.0V (Typ.)
applicationDMPC
