LM185WH1-TLC5

LM185WH1-TLC5
LM185WH1-TLC5
LM185WH1-TLC5 thumb LM185WH1-TLC5 thumb
Waitohu
LG Display
Rahi
18.5
Taupānga
DMPC
Whakatau
1366×768
Te tito
LCM
Tirohanga
300
CR
1000:1
Nga Tae
16.7M
Whakamuri
CCFL
Atanga
LVDS
In Stock
3546
Whakatakotoranga

Nama Wahi LM185WH1-TLC5
WaitohuLG Display
Rahi18.5
TaupāngaDMPC
Whakatau1366×768
Te titoLCM
Tirohanga300
CR1000:1
Nga Tae16.7M
WhakamuriCCFL
AtangaLVDS
panel brandLG Display
panel modelLM185WH1-TLC5
panel type a-Si TFT-LCD , LCM
panel size18.5 inch
resolution1366(RGB)×768 , WXGA
display modeTN, Normally White, Transmissive
active area409.8×230.4 mm
surface
brightness300 cd/m² (Typ.)
contrast ratio1000:1 (Typ.)
display colors16.7M (6-bit + Hi-FRC), CIE193172%
response time5 (Typ.)(Tr+Td)
viewing angle85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type2 pcsCCFL
signal interfaceLVDS (1 ch, 8-bit)
applicationDMPC
Tauira Whanau
LM185WH1-TLA1 LG Display 18.5 1366×768
LM185WH1-TLC5 LG Display 18.5 1366×768
LM185WH1-TLD1 LG Display 18.5 1366×768
LM185WH1-TLD3 LG Display 18.5 1366×768
LM185WH1-TLF4 LG Display 18.5 1366×768
LM185WH1-TLH1 LG Display 18.5 1366×768
LM185WH2-T2BB LG Display 18.5 1366×768
LM185WH2-TLA1 LG Display 18.5 1366×768
LM185WH2-TLD1 LG Display 18.5 1366×768
LM185WH2-TLE2 LG Display 18.5 1366×768
