| Nama Wahi | LTM236FL01 |
| Waitohu | Samsung |
| Rahi | 23.6 |
| Taupānga | DMPC |
| Whakatau | 3840×2160 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | SAMSUNG |
| panel model | LTM236FL01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 23.6 inch |
| resolution | 3840(RGB)×2160 , UHD |
| display mode | PLS, Normally Black, Transmissive |
| active area | 521.28×293.22 mm |
| outline | 544.8×320.5×11 mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (8-bit), sRGB100% |
| response time | 14 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4 stringsWLEDWithout Driver |
| signal interface | eDP (4 Lanes), 51 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
