| Nama Wahi | LH570QH6-SD01 |
| Waitohu | LG Display |
| Rahi | 5.7 |
| Taupānga | Mobile Phone |
| Whakatau | 1440×2880 |
| Te tito | Assembly , a-Si TF |
| Tirohanga | |
| CR | 1500:1 |
| Nga Tae | 16.7M |
| Whakamuri | 4S3P |
| Atanga | MIPI |
| manufacturer | LG Display |
| screen size | 5.7 inch |
| pixel number | 1440(RGB)×2880 564PPI |
| active area(mm) | 64.8 × 129.6 (H×V) |
| bezel area(mm) | - |
| luminance | 500 cd/m² (Typ.) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 85% NTSC |
| mass | 26.6±2.7g |
| refresh rate | 60Hz |
| signal type | MIPI (4 data lanes) , 54 pins Connector |
| voltage supply | 1.8/3.3/5.5/-5.5V (Typ.)(VDDI/VPNL/DDVDL/DDVDH) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model name | LH570QH6-SD01 |
| screen type | Assembly , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 68.72 × 145.7 (H×V×D) |
| treatment | Hard coating |
| contrast ratio | 1500 : 1 (Typ.) (TM) |
| response | 25 (Typ.)(Tr+Td) ms |
| work mode | - |
| backlight | 4S3P WLED , No Driver |
| used for | Mobile Phone |
| touchscreen | PCAP |
