| Nama Wahi | DLC0570BDG-3 |
| Waitohu | Other |
| Rahi | 5.7 |
| Taupānga | IA |
| Whakatau | 640×480 |
| Te tito | LCM |
| Tirohanga | 900 |
| CR | 300:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | DLC |
| panel model | DLC0570BDG-3 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 5.7 inch |
| resolution | 640(RGB)×480 , VGA |
| display mode | TN, Normally White, Transmissive |
| active area | 115.2×86.4 mm |
| outline | 127.4×98.43×7 mm |
| surface | |
| brightness | 900 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | 262K (6-bit), CIE193150% |
| response time | 15/35 (Typ.)(Tr/Td) |
| viewing angle | 70/70/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S7PWLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| C555001 | SII | 5.7 | 320×240 |
| DLC0570BDG-3 | Other | 5.7 | 640×480 |
| DLC0570BDG-T-2 | Other | 5.7 | 640×480 |
| DLC0570CDG-1 | Other | 5.7 | 320×240 |
| DLC0570FDG | Other | 5.7 | 320×240 |
| HTW-G320240B2 | Other | 5.7 | 320×240 |
| LQ057Q3DC02 | SHARP | 5.7 | 320×240 |
| PD057VU7 | E Ink | 5.7 | 320×240 |
| TM057QDHG04 | Tianma | 5.7 | 640×480 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| EL640.480-A4 SBS | PLANAR | 10.4 | 640×480 |
| G057QN01 V0 | AUO | 5.7 | 320×240 |
| G057QN01 V1 | AUO | 5.7 | 320×240 |
| KG057QV1CA-G020 | Kyocera | 5.7 | 320×240 |
| LQ121S1DG41 | SHARP | 12.1 | 800×600 |
| LQ190E1LW02 | SHARP | 19.0 | 1280×1024 |
| LQ9D001 | SHARP | 8.4 | 640×480 |
| LTM121SI-T01 | Samsung | 12.1 | 800×600 |
| TM121SV-02L11 | SANYO | 12.1 | 800×600 |
