LC320EUD-SDF3

LC320EUD-SDF3
LC320EUD-SDF3 thumb
Waitohu
LG Display
Rahi
31.5
Taupānga
LCTV
Whakatau
1920×1080
Te tito
LCM
Tirohanga
400
CR
1600:1
Nga Tae
16.7M/1.06B
Whakamuri
WLED
Atanga
LVDS
In Stock
19083
Whakatakotoranga

Nama Wahi LC320EUD-SDF3
WaitohuLG Display
Rahi31.5
TaupāngaLCTV
Whakatau1920×1080
Te titoLCM
Tirohanga400
CR1600:1
Nga Tae16.7M/1.06B
WhakamuriWLED
AtangaLVDS
panel brandLG Display
panel modelLC320EUD-SDF3
panel type a-Si TFT-LCD , LCM
panel size31.5 inch
resolution1920(RGB)×1080 , FHD
display modeIPS, Normally Black, Transmissive
active area698.4×392.85 mm
outline735.4×433 mm
surfaceAntiglare (Haze 10%), Hard coating (2H)
brightness400 cd/m² (Typ.)
contrast ratio1600:1 (Typ.)
display colors16.7M/1.06B (8-bit / 8-bit + Dithering)
response time5 (Typ.)(G to G); 6 (Typ.)(MPRT)
viewing angle89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
frequency120Hz+120Hz
lamp typeWLEDEmbedded (LED Driver)
signal interfaceLVDS (4 ch, 8/10-bit), 92 pins
input voltage12.0V (Typ.)
applicationLCTV
