LG Display LC320EUD-SDA2 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


LC320EUD-SDA2

LC320EUD-SDA2
LC320EUD-SDA2 thumb
Waitohu
LG Display
Rahi
31.5
Taupānga
LCTV
Whakatau
1920×1080
Te tito
LCM
Tirohanga
450
CR
1600:1
Nga Tae
16.7M/1.06B
Whakamuri
WLED
Atanga
LVDS
In Stock
230
Whakatakotoranga

Nama Wahi LC320EUD-SDA2
WaitohuLG Display
Rahi31.5
TaupāngaLCTV
Whakatau1920×1080
Te titoLCM
Tirohanga450
CR1600:1
Nga Tae16.7M/1.06B
WhakamuriWLED
AtangaLVDS
panel brandLG Display
panel modelLC320EUD-SDA2
panel type a-Si TFT-LCD , LCM
panel size31.5 inch
resolution1920(RGB)×1080 , FHD
display modeS-IPS, Normally Black, Transmissive
active area698.4×392.85 mm
outline735.4×433 mm
surfaceAntiglare (Haze 10%), Hard coating (3H)
brightness450 cd/m² (Typ.)
contrast ratio1600:1 (Typ.)
display colors16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
response time5 (Typ.)(G to G); 8 (Typ.)(MPRT)
viewing angle89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
frequency120Hz+120Hz
lamp typeWLEDEmbedded (LED Driver)
signal interfaceLVDS (4 ch, 8/10-bit), 92 pins
input voltage12.0V (Typ.)
applicationLCTV
Tauira Whanau
LC320EUA-PEF1 LG Display 31.5 1920×1080
LC320EUD-SDA2 LG Display 31.5 1920×1080
LC320EUD-SDF3 LG Display 31.5 1920×1080
LC320EUD-SDP1 LG Display 31.5 1920×1080
LC320EUD-SEM1 LG Display 31.5 1920×1080
LC320EUE-SEM1 LG Display 31.5 1920×1080
LC320EUN-SEM2 LG Display 31.5 1920×1080
LC320EXJ-SEK1 LG Display 31.5 1366×768
LC320EXN-SDA1 LG Display 31.5 1366×768
LC320EXN-SEA2 LG Display 31.5 1366×768
