Nama Wahi | V150V1-T02 |
Waitohu | Innolux |
Rahi | 15.0 |
Taupānga | LCTV |
Whakatau | 640×480 |
Te tito | LCM |
Tirohanga | 500 |
CR | 800:1 |
Nga Tae | 16.2M |
Whakamuri | CCFL |
Atanga | TTL |
panel brand | CMO |
panel model | V150V1-T02 |
panel type | a-Si TFT-LCD , LCM |
panel size | 15.0 inch |
resolution | 640(RGB)×480 , VGA |
display mode | Super MVA, Normally Black, Transmissive |
active area | 305.28×228.96 mm |
outline | 331.2×256 mm |
surface | Antiglare (Haze 25%), Hard coating (3H), Reflection 2.0% (Max.) |
brightness | 500 cd/m² (Typ.) |
contrast ratio | 800:1 (Typ.) |
display colors | 16.2M (6-bit + FRC), CIE193172% |
response time | 15/10 (Typ.)(Tr/Td) |
viewing angle | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
frequency | 60Hz |
lamp type | 4 pcsCCFLWithout Driver |
signal interface | TTL (1 ch, 8-bit), 50 pins |
input voltage | 5.0V (Typ.)(VCC) |
application | LCTV |
