| Nama Wahi | LB035Q01-TJ01 |
| Waitohu | LG Display |
| Rahi | 3.5 |
| Taupānga | PND |
| Whakatau | 320×240 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 300:1 |
| Nga Tae | 16.7M |
| Whakamuri | No B/L |
| Atanga | TTL |
| panel brand | LG.Philips LCD |
| panel model | LB035Q01-TJ01 |
| panel type | a-Si TFT-LCD , CELL |
| panel size | 3.5 inch |
| resolution | 320(RGB)×240 , QVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 70.08×52.56 mm |
| outline | 78.1×62.95×1.53 mm |
| surface | Hard coating |
| contrast ratio | 300:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 70Hz |
| signal interface | TTL (1 ch, 8-bit), 45 pins |
| input voltage | 3.3/5.0V (Typ.)(VDD/AVDD) |
| rohs: | |
| application | PND |
