| Nama Wahi | LQ036T1DG01 |
| Waitohu | SHARP |
| Rahi | 3.6 |
| Taupānga | PND |
| Whakatau | 272×480 |
| Te tito | LCM |
| Tirohanga | 410 |
| CR | 300:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SHARP |
| panel model | LQ036T1DG01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 3.6 inch |
| resolution | 272(RGB)×480 , WQVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 44.472×78.48 mm |
| outline | 51.8×90 mm |
| surface | Antiglare, Hard coating (2H) |
| brightness | 410 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | 262K (6-bit), CIE193150% |
| response time | 30/30 (Typ.)(Tr/Td) |
| viewing angle | 40/60/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | Parallel RGB + SPI, 67 pins |
| input voltage | 1.8/2.5V (Typ.)(VDDIO/VCI) |
| application | PND |
