| Nama Wahi | LQ043T1DH42 |
| Waitohu | SHARP |
| Rahi | 4.3 |
| Taupānga | PND |
| Whakatau | 480×272 |
| Te tito | LCM |
| Tirohanga | 360 |
| CR | 300:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SHARP |
| panel model | LQ043T1DH42 2 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.3 inch |
| resolution | 480×272(RGB) , WQVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 95.04×53.856 mm |
| outline | 105.5×67.2×4.45 mm |
| surface | Antiglare, Hard coating (2H) |
| brightness | 360 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | 262K (6-bit), CIE193148% |
| response time | 8/8 (Typ.)(Tr/Td) |
| viewing angle | 45/45/20/55 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 9S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| input voltage | 1.8/(3.3/2.8)V (Typ.)(VDDIO/VCI) |
| application | PND |
| LQ043T1DG03 | SHARP | 4.3 | 480×272 |
| LQ043T1DG03B | SHARP | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LQ043T1DH42 | SHARP | 4.3 | 480×272 |
| LQ043T3DG01 | SHARP | 4.3 | 480×272 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX04 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0E | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01 | SHARP | 4.3 | 480×800 |
| LQ043Y1DX02 | SHARP | 4.3 | 480×800 |
| AT050TN34 | Innolux | 5.0 | 480×272 |
| LB035Q02-TD01 | LG Display | 3.5 | 320×240 |
| LMS430HF18 | Samsung | 4.3 | 480×272 |
| LMS480KC01 | Samsung | 4.8 | 800×480 |
| LMS480KC02 | Samsung | 4.8 | 800×480 |
| LQ043T3DX0E | SHARP | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| LR430RC9001 | Innolux | 4.3 | 480×272 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
| TS047NAARB01-00 | Tianma | 4.7 | 480×272 |
