| Nama Wahi | LA123WF1-SR02 |
| Waitohu | LG Display |
| Rahi | 12.3 |
| Taupānga | Automotive Display |
| Whakatau | 1920×720 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | RSDS |
| brand | LG Display |
| diagonal size | 12.3 inch |
| pixel format | 1920(RGB)×720 167PPI |
| active area | 292.032(H)×109.512(V) mm |
| bezel area | - |
| luminance | 600 cd/m² (Min.) |
| view direction | Symmetry |
| viewing angle | 89/89/89/89 (Min.)(CR≥10) |
| support color | 16.7M 86% NTSC |
| weight | 390/405g (Typ./Max.) |
| frame rate | 60Hz |
| interface type | RSDS (2 Channel) , 110 pins FPC |
| power supply | 3.3/13.0V (Typ.)(VCC/VDD) |
| environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| model | LA123WF1-SR02 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 310(H)×128(V) ×11.05(D) mm |
| treatment | Antiglare, Antireflection |
| contrast ratio | 800:1 (Min.) (TM) |
| response time | 30 (Typ.)(Tr+Td) |
| operating mode | IPS, Normally Black, Transmissive |
| light source | WLED [8S6P] , 10K hours , W/O Driver |
| designed for | Automotive Display |
| touch panel | Without |
