| Nama Wahi | HV121P01-101 |
| Waitohu | HYDIS |
| Rahi | 12.1 |
| Taupānga | PAD |
| Whakatau | 1400×1050 |
| Te tito | LCM |
| Tirohanga | 190 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | BOE HYDIS |
| panel model | HV121P01-101 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1400(RGB)×1050 , SXGA+ |
| display mode | AFFS, Normally Black, Transmissive |
| active area | 245.7×184.275 mm |
| outline | 270×199×7 mm |
| surface | Antiglare (Haze 40%), Hard coating (2H) |
| brightness | 190 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit), CIE193143% |
| response time | 20/20 (Typ.)(Tr/Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
