| Nama Wahi | HT12X21-240 |
| Waitohu | HYDIS |
| Rahi | 12.1 |
| Taupānga | PAD |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 180 |
| CR | 450:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | BOE HYDIS |
| panel model | HT12X21-240 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | AFFS, Normally Black, Transmissive |
| active area | 245.76×184.32 mm |
| outline | 270×199×7 mm |
| surface | Glare (Haze 0%), Hard coating (2H) |
| brightness | 180 cd/m² (Typ.) |
| contrast ratio | 450:1 (Typ.) |
| display colors | 262K (6-bit), CIE193140% |
| response time | 40 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
| G121SN01 V4 | AUO | 12.1 | 800×600 |
| G121X1-L01 | Innolux | 12.1 | 1024×768 |
| HT12X12-100 | HYDIS | 12.1 | 1024×768 |
| HT12X21-220 | HYDIS | 12.1 | 1024×768 |
| HT12X21-221 | HYDIS | 12.1 | 1024×768 |
| HT12X21-230 | HYDIS | 12.1 | 1024×768 |
| HT12X21-240 | HYDIS | 12.1 | 1024×768 |
| HT12X21-351 | HYDIS | 12.1 | 1024×768 |
| LTM12C505K | TOSHIBA | 12.1 | 1024×768 |
| NL8060BC31-13A | NLT | 12.1 | 800×600 |
| B101EW04 V0 | AUO | 10.1 | 1280×800 |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| BP080WX1-100 | BOE | 8.0 | 1280×800 |
| HQ097QX1-IPS | Other | 9.7 | 2048×1536 |
| HSD101PWW1-A00 | HannStar | 10.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| N101BCG-L21 | Innolux | 10.1 | 1366×768 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
