| Nama Wahi | HT12X21-230 |
| Waitohu | HYDIS |
| Rahi | 12.1 |
| Taupānga | PAD |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 180 |
| CR | 450:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | BOE HYDIS |
| panel model | HT12X21-230 2 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | AFFS, Normally Black, Transmissive |
| active area | 245.76×184.32 mm |
| outline | 270×199×7 mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| brightness | 180 cd/m² (Typ.) |
| contrast ratio | 450:1 (Typ.) |
| display colors | 262K (6-bit), CIE193140% |
| response time | 40 (Typ.)(Tr+Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
| HT12X12-100 | HYDIS | 12.1 | 1024×768 |
| HT12X21-220 | HYDIS | 12.1 | 1024×768 |
| HT12X21-221 | HYDIS | 12.1 | 1024×768 |
| HT12X21-230 | HYDIS | 12.1 | 1024×768 |
| HT12X21-240 | HYDIS | 12.1 | 1024×768 |
| HT12X21-351 | HYDIS | 12.1 | 1024×768 |
| LB121S03-TD01 | LG Display | 12.1 | 800×600 |
| LTD121EW3D | TOSHIBA | 12.1 | 1280×800 |
| LTN121AT04-001 | Samsung | 12.1 | 1280×800 |
| NL8060BC31-17 | NLT | 12.1 | 800×600 |
| B070EAN01.6 | AUO | 7.0 | 800×1280 |
| B101EAN01.3 | AUO | 10.1 | 1280×800 |
| B101XAN02.0 | AUO | 10.1 | 1366×768 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| HE070IA-04R | Innolux | 7.0 | 800×1280 |
| LP079X01-SMA1 | LG Display | 7.9 | 768×1024 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| N080ICE-GB0 Rev.A0 | Innolux | 8.0 | 800×1280 |
| YXD090TN02-40NM01 | SEBO | 9.0 | 1280×800 |
