| Nama Wahi | HQ097QX1-IPS |
| Waitohu | Other |
| Rahi | 9.7 |
| Taupānga | PAD |
| Whakatau | 2048×1536 |
| Te tito | LCM |
| Tirohanga | 420 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | No Brand |
| panel model | HQ097QX1-IPS 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.7 inch |
| resolution | 2048(RGB)×1536 , QXGA |
| display mode | PLS, Normally Black, Transmissive |
| active area | 196.608×147.456 mm |
| outline | 208.88×167.12 mm |
| surface | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| brightness | 420 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | eDP (4 Lanes), 51 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
