| Nama Wahi | LTN097XL01-A02 |
| Waitohu | Samsung |
| Rahi | 9.7 |
| Taupānga | PAD |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 390 |
| CR | 900:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTN097XL01-A02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.7 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | PLS, Normally Black, Transmissive |
| active area | 196.608×147.456 mm |
| surface | Glare (Haze 0%), Hard coating (3H) |
| brightness | 390 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) |
| display colors | 262K (6-bit), CIE193152% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
| ED097OC4 | E Ink | 9.7 | 1200×825 |
| HQ097QX1-IPS | Other | 9.7 | 2048×1536 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LP097QX2-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLA2 | LG Display | 9.7 | 1024×768 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| LTN097XL01-A02 | Samsung | 9.7 | 1024×768 |
| LTN097XL02-A01 | Samsung | 9.7 | 1024×768 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| TV097X0M-NS0 | BOE | 9.7 | 768×1024 |
| BP070WSA-400 | BOE | 7.0 | 1024×600 |
| HV121WX5-114 | HYDIS | 12.1 | 1280×800 |
| LD070WX6-SM01 | LG Display | 7.0 | 800×1280 |
| LP116WH4-SLA1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN2 | LG Display | 11.6 | 1366×768 |
| LTL097QL01-W01 | Samsung | 9.7 | 2048×1536 |
| LTN097QL01-A02 | Samsung | 9.7 | 2048×1536 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
| P101KDA-AP1 | Innolux | 10.1 | 1200×1920 |
