| Nama Wahi | HT15X15-D01 |
| Waitohu | HYDIS |
| Rahi | 15.0 |
| Taupānga | DMPC |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 500:1 |
| Nga Tae | 16.2M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | BOE HYDIS |
| panel model | HT15X15-D01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 15.0 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | TN, Normally White, Transmissive |
| active area | 304.128×228.096 mm |
| outline | 331.6×254.7×13 mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC), CIE193170% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | DMPC |
| AA150XN01 | Mitsubishi | 15.0 | 1024×768 |
| G150X1-L01 | Innolux | 15.0 | 1024×768 |
| G150XGE-L04 | Innolux | 15.0 | 1024×768 |
| HT150X02-101 | BOE | 15.0 | 1024×768 |
| HT15X15-D01 | HYDIS | 15.0 | 1024×768 |
| HT15X23-100 | HYDIS | 15.0 | 1024×768 |
| HT15X31-100 | HYDIS | 15.0 | 1024×768 |
| LTM150XH-L04 | Samsung | 15.0 | 1024×768 |
| N150P2-L04 | IDTech | 15.0 | 1400×1050 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| L170E3 EC-5 | AUO | 17.0 | 1280×1024 |
| LC215DT4A | PANDA | 21.5 | 1920×1080 |
| LM200WD3-TLA1 | LG Display | 20.0 | 1600×900 |
| LM215DT1A | PANDA | 21.5 | 1920×1080 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| LTM240CL01 | Samsung | 24.0 | 1920×1200 |
| M156B1-L02 | Innolux | 15.6 | 1366×768 |
| M185XW01 V8 | AUO | 18.5 | 1366×768 |
| M200HJJ-P01 | Innolux | 19.5 | 1920×1080 |
| NL10276AC30-03 | NLT | 15.0 | 1024×768 |
