| Nama Wahi | HSD123JPW3-A10 |
| Waitohu | HannStar |
| Rahi | 12.3 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 1920×720 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1500:1 |
| Nga Tae | 16.7M |
| Whakamuri | 11S4P |
| Atanga | LVDS |
| manufacturer | HannStar |
| model name | HSD123JPW3-A10 |
| screen size | 12.3 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1920(RGB)×720 167PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 292.032 × 109.512 (H×V) |
| outline(mm) | 302 × 125.4 × 14.2 (H×V×D) |
| bezel area(mm) | - |
| treatment | Glare (Haze 0%), Hard coating |
| luminance | 850 cd/m² (Typ.) |
| contrast ratio | 1500 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | IPS Pro, Normally Black, Transmissive |
| color depth | 16.7M 75% NTSC |
| backlight | 11S4P WLED , 30K hours , No Driver |
| mass | 345/378g (Typ./Max.) |
| used for | Outdoor High Brightness Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (2 ch, 8-bit) , Connector 50 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
