| Nama Wahi | HSD090JFW1-A02 |
| Waitohu | HannStar |
| Rahi | 9.0 |
| Taupānga | Automotive Display |
| Whakatau | 1024×600 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.2M |
| Whakamuri | 3S13P |
| Atanga | LVDS |
| manufacturer | HannStar |
| model name | HSD090JFW1-A02 |
| screen size | 9.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1024(RGB)×600 (WSVGA) 132PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 196.608 × 114.15 (H×V) |
| outline(mm) | 211.1 × 126.5 × 6 (H×V×D) |
| bezel area(mm) | 200.01 × 117.55 (H×V) |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 17/18 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | IPS Pro, Normally Black, Transmissive |
| color depth | 16.2M 50% NTSC |
| backlight | 3S13P WLED , 15K hours , No Driver |
| mass | 226g (Typ.) |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 8-bit) , FPC 40 pins |
| voltage supply | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
