| Nama Wahi | HSD070BHW1-A00 |
| Waitohu | HannStar |
| Rahi | 7.0 |
| Taupānga | Pad & Tablet |
| Whakatau | 720×1280 |
| Te tito | CELL , a-Si TFT-LC |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | |
| manufacturer | HannStar |
| screen size | 7.0 inch |
| pixel number | 720(RGB)×1280 (WXGA) 210PPI |
| active area(mm) | 86.94 × 154.56 (H×V) |
| luminance | 0 cd/m² |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| good view at | Symmetry |
| glass thickness | 0.40+0.40 mm |
| color depth | 16.7M 70% NTSC |
| mass | - |
| refresh rate | - |
| driver ic list | Built-in COG HX8394-A01, HX8394-B, NT35520, NT35521, OTM1283A, OTM1288A |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model name | HSD070BHW1-A00 |
| screen type | CELL , a-Si TFT-LCD |
| arrangement | RGB Ttilt Stripe |
| outline(mm) | 89.94 × 162.56 × 0.8 (H×V×D) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| response | 10/20 (Typ.)(Tr/Td) ms |
| work mode | IPS Pro, Normally Black, Transmissive |
| transmissivity | 4.0% (Typ.)(with Polarizer) |
| backlight | No B/L |
| used for | Pad & Tablet |
| touchscreen | Without |
