| Nama Wahi | CLAA080WQ05 XN |
| Waitohu | CPT |
| Rahi | 8.0 |
| Taupānga | Pad & Tablet Industr |
| Whakatau | 800×1280 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | 3S7P |
| Atanga | |
| manufacturer | CPT |
| screen size | 8.0 inch |
| pixel number | 800(RGB)×1280 (WXGA) 188PPI |
| active area(mm) | 107.64 × 172.224 (H×V) |
| bezel area(mm) | - |
| luminance | 350 (Typ.)(cd/m²) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 58% NTSC |
| mass | 115g (Max.) |
| refresh rate | 60Hz |
| model name | CLAA080WQ05 XN |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 114.6 × 184.7 × 4.56 (H×V×D) |
| treatment | Hard coating (3H) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| work mode | HFFS, Normally Black, Transmissive |
| response | 30 (Typ.)(Tr+Td) ms |
| backlight | 3S7P WLED , 15K hours , No Driver |
| used for | Pad & Tablet Industrial |
| touchscreen | Without |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA01 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
