| Nama Wahi | CLAA080WK0A XN |
| Waitohu | CPT |
| Rahi | 8.0 |
| Taupānga | Automotive Display |
| Whakatau | 1280×720 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | |
| brand | CPT |
| model | CLAA080WK0A XN |
| diagonal size | 8.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×720 [WXGA] 183PPI |
| configuration | RGB Vertical Stripe |
| active area | 177.024(H)×99.576(V) mm |
| outline dim. | 182.8(H)×116.9(V) ×6.8(D) mm |
| bezel area | 179.024(H)×101.576(V) mm |
| treatment | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 600 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | HFFS, Normally Black, Transmissive |
| support color | 16.7M 70% NTSC |
| light source | WLED [9S3P] , 50K hours , W/O Driver |
| weight | 120/230g (Typ./Max.) |
| designed for | Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| CLAA080NA01 CW | CPT | 8.0 | 1024×600 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| CLAA080WQ05 | CPT | 8.0 | 800×1280 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
