| Nama Wahi | CLAA080WK02 XN |
| Waitohu | CPT |
| Rahi | 8.0 |
| Taupānga | Automotive Display |
| Whakatau | 1280×720 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | CPT |
| model | CLAA080WK02 XN |
| diagonal size | 8.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×720 [WXGA] 183PPI |
| configuration | RGB Vertical Stripe |
| active area | 177.024(H)×99.576(V) mm |
| outline dim. | 186.5(H)×117.22(V) ×13.1(D) mm |
| bezel area | 179.03(H)×101.58(V) mm |
| treatment | Antiglare (Haze 25%) |
| luminance | 600 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | HFFS, Normally Black, Transmissive |
| support color | 262K/16.7M 70% NTSC |
| light source | WLED [5S4P] , 30K hours , W/O Driver |
| weight | TBD |
| designed for | Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| power supply | 3.3/12.4/22/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
