| Nama Wahi | CLAA070LQ02 XN |
| Waitohu | CPT |
| Rahi | 7.0 |
| Taupānga | Automotive Display |
| Whakatau | 800×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 7S2P |
| Atanga | LVDS |
| manufacturer | CPT |
| model name | CLAA070LQ02 XN |
| screen size | 7.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 152.4 × 91.44 (H×V) |
| outline(mm) | 165 × 104 × 7.3 (H×V×D) |
| bezel area(mm) | 154.4 × 93.44 (H×V) |
| treatment | Antiglare (Haze 25%) |
| luminance | 760 cd/m² (Typ.) |
| contrast ratio | 900 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Tf) ms |
| good view at | Symmetry |
| work mode | HFFS, Normally Black, Transmissive |
| color depth | 262K/16.7M 70% NTSC |
| backlight | 7S2P WLED , 30K hours , No Driver |
| mass | 175g (Typ.) |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 6/8-bit) , FPC 60 pins |
| voltage supply | 3.3/13.0/20.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. ratings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
