| Nama Wahi | C100HAT01.0 |
| Waitohu | AUO |
| Rahi | 10.0 |
| Taupānga | Automotive Display |
| Whakatau | 1560×700 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | |
| manufacturer | AUO |
| model name | C100HAT01.0 |
| screen size | 10.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1560(RGB)×700 171PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 231.66 × 103.95 (H×V) |
| outline(mm) | 259.36 × 131.32 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare, Antireflection |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| response | 30 (Max.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | AHVA, Normally Black, Transmissive |
| color depth | 16.7M |
| backlight | WLED |
| mass | 375±38g |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | - |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
