SVA-NEC SVA101WV1(01TA)(A) Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


SVA101WV1(01TA)(A)

SVA101WV1(01TA)(A)
SVA101WV1(01TA)(A)
SVA101WV1(01TA)(A)
SVA101WV1(01TA)(A) thumb SVA101WV1(01TA)(A) thumb SVA101WV1(01TA)(A) thumb
Waitohu
SVA-NEC
Rahi
10.0
Taupānga
NOPC
Whakatau
1024×576
Te tito
LCM
Tirohanga
200
CR
400:1
Nga Tae
262K
Whakamuri
WLED
Atanga
LVDS
In Stock
5422
Whakatakotoranga

Nama Wahi SVA101WV1(01TA)(A)
WaitohuSVA-NEC
Rahi10.0
TaupāngaNOPC
Whakatau1024×576
Te titoLCM
Tirohanga200
CR400:1
Nga Tae262K
WhakamuriWLED
AtangaLVDS
panel brandSVA-NEC
panel modelSVA101WV1(01TA)(A)
panel type a-Si TFT-LCD , LCM
panel size10.0 inch
resolution1024(RGB)×576 , WSVGA
display modeTN, Normally White, Transmissive
active area221.184×124.416 mm
outline235×143×5.2 mm
surfaceAntiglare, Hard coating (3H)
brightness200 cd/m² (Typ.)
contrast ratio400:1 (Typ.)
display colors262K (6-bit), CIE193145%
response time8 (Typ.)(Tr+Td)
viewing angle45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp typeWLEDEmbedded (LED Driver)
signal interfaceLVDS (1 ch, 6-bit), 40 pins
input voltage3.3V (Typ.)
applicationNOPC
Tauira Whanau
HSD100PXN1-A00 HannStar 10.0 1024×768
HSD100PXN1-A00-C11 HannStar 10.0 1024×768
LM100SS1T522 SHARP 10.0 800×600
LT100AA40000 TOSHIBA 10.0 800×600
PM100WX2 E Ink 10.0 800×480
PW100XS1 E Ink 10.0 640×468
PW100XS5 E Ink 10.0 640×468
SVA101WV1(01TA)(A) SVA-NEC 10.0 1024×576
SX25S004 KOE 10.0 800×600
TM100SV-A02-01 SANYO 10.0 800×600
