| Nama Wahi | C084XAT01.0 |
| Waitohu | AUO |
| Rahi | 8.4 |
| Taupānga | Automotive Display |
| Whakatau | 1024×768 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | AUO |
| model name | C084XAT01.0 |
| screen size | 8.4 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1024(RGB)×768 (XGA) 152PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 170.496 × 127.872 (H×V) |
| outline(mm) | 185.5 × 143.9 (H×V×D) |
| bezel area(mm) | 176.92 × 134.33 (H×V) |
| treatment | Antiglare, Antireflection |
| luminance | - |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| viewing angle | - |
| response | 30 (Max.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | AHVA, Normally Black, Transmissive |
| color depth | 16.7M |
| backlight | WLED |
| mass | 420g±42g |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | PCAP |
| signal type | LVDS (1 ch, 8-bit) , 40 pins Connector |
| max. ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| LB084S02-TD01 | LG Display | 8.4 | 800×600 |
| LQ084V1DG21E | SHARP | 8.4 | 640×480 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| LQ9D001 | SHARP | 8.4 | 640×480 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| LTM08C351S | TOSHIBA | 8.4 | 800×600 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| NL6448BC26-09 | NLT | 8.4 | 640×480 |
| NL6448BC26-15 | NLT | 8.4 | 640×480 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
