| Nama Wahi | BTL454885-W698L |
| Waitohu | BOE |
| Rahi | 4.5 |
| Taupānga | MPH |
| Whakatau | 480×854 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | BOE |
| panel model | BTL454885-W698L |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.5 inch |
| resolution | 480(RGB)×854 , FWVGA |
| display mode | ADS, Normally Black, Transmissive |
| active area | 55.44×98.637 mm |
| outline | 59.9×108.88 mm |
| surface | Glare (Haze 0%), Hard coating |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193168% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 8S1PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 24 pins |
| input voltage | 1.8/2.85V (Typ.)(IOVCC/VCI) |
| application | MPH |
