| Nama Wahi | ACX565AKM-7 |
| Waitohu | SONY |
| Rahi | 3.5 |
| Taupānga | MPH |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 275 |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | CDP |
| panel brand | SONY |
| panel model | ACX565AKM-7 |
| panel type | LTPS TFT-LCD , LCM |
| panel size | 3.5 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | VSPEC II, Normally Black, Transflective |
| active area | 76.8×46.08 mm |
| outline | 87.9×52.18 mm |
| surface | |
| brightness | 275 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.)(Transmissive)24:1 (Typ.)(Reflective) |
| display colors | 16.7M (8-bit), CIE193170% |
| response time | 12/7 (Typ.)(Tr/Td) |
| viewing angle | |
| frequency | 60Hz |
| lamp type | 3S2PWLEDWithout Driver |
| signal interface | CDP (2 Lane) + SPI, 24 pins |
| input voltage | 1.8/2.75V (Typ.)(VDDI/VDD) |
| application | MPH |
