| Nama Wahi | BTL455496-W613L |
| Waitohu | BOE |
| Rahi | 4.5 |
| Taupānga | MPH |
| Whakatau | 540×960 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 520:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | BOE |
| panel model | BTL455496-W613L |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.5 inch |
| resolution | 540(RGB)×960 , qHD |
| display mode | TN, Normally White, Transmissive |
| active area | 55.485×98.64 mm |
| outline | 60.71×109.1×1.8 mm |
| surface | Clear |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 520:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 5S2PWLEDWithout Driver |
| signal interface | MIPI (3 data lanes), 30 pins |
| input voltage | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| rohs: | |
| application | MPH |
