| Nama Wahi | AT070MP11 |
| Waitohu | Mitsubishi |
| Rahi | 7.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 800×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | Mitsubishi |
| model name | AT070MP11 |
| screen size | 7.0 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 152.4 × 91.44 (H×V) |
| outline(mm) | 169.8 × 109.7 × 9.4 (H×V×D) |
| bezel area(mm) | 154.4 × 93.5 (H×V) |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 1300 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 4/12 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | SWV, Normally Black, Transmissive |
| color depth | 262K/16.7M 50% NTSC |
| backlight | WLED , 100K hours , No Driver |
| mass | 200g |
| used for | Industrial Outdoor High Brightness Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
