| Nama Wahi | AMS767KC04-1 |
| Waitohu | Samsung |
| Rahi | 7.7 |
| Taupānga | PAD |
| Whakatau | 1280×800 |
| Te tito | Assembly |
| Tirohanga | 250 |
| CR | 3400:1 |
| Nga Tae | 16.7M |
| Whakamuri | self |
| Atanga | MIPI |
| panel brand | SAMSUNG |
| panel model | AMS767KC04-1 |
| panel type | AM-OLED , Assembly |
| panel size | 7.7 inch |
| resolution | 1280(RGB)×800 , WXGA |
| active area | 165.12×103.2 mm |
| outline | 197.7×128.4 mm |
| surface | Anti Fingerprint |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 3400 : 1 (Min.) |
| display colors | 16.7M (8-bit), CIE1931110% |
| viewing angle | 88/88/88/88 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | MIPI (4 data lanes), 44 pins |
| input voltage | 6.3/1.8/3.0/5.8V (VDCDC/VDD3/VCI/VLIN1) |
| application | PAD |
| AMS767KC04-1 | Samsung | 7.7 | 1280×800 |
| KCS077VG2EA-A43 | Kyocera | 7.7 | 640×480 |
| LM8V301 | SHARP | 7.7 | 640×480 |
| LM8V302 | SHARP | 7.7 | 640×480 |
| LM8V302H | SHARP | 7.7 | 640×480 |
| LM8V31 | SHARP | 7.7 | 640×480 |
| LM8V311 | SHARP | 7.7 | 640×480 |
| LTM07C757 | TOSHIBA | 7.7 | 400×234 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| B080XAT01.1 | AUO | 7.9 | 768×1024 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LSL080AL02-B01 | Samsung | 8.0 | 800×1280 |
| LTN097XL02-A01 | Samsung | 9.7 | 1024×768 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| VVX07H005A00 | Panasonic | 7.0 | 800×1280 |
