| Nama Wahi | AM-19201200CTZQW-02 |
| Waitohu | AMPIRE |
| Rahi | 10.1 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1920×1200 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AMPIRE |
| model | AM-19201200CTZQW-02 |
| diagonal size | 10.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1920(RGB)×1200 [WUXGA] 225PPI |
| configuration | RGB Vertical Stripe |
| active area | 216.576(H)×135.36(V) mm |
| outline dim. | 244.8(H)×155.3(V) ×7.07(D) mm |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | AHVA, Normally Black, Transmissive |
| support color | 16.7M 49% NTSC |
| light source | WLED , 50K hours , With LED Driver |
| weight | - |
| designed for | Industrial Outdoor High Brightness |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (2 ch, 8-bit) , 45 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
